generate a triangle
GenerateTriangle( n, magnitude, frequency, phase, asymmetry )
posint, number of samples to generate
realcons, magnitude of the signal
realcons, the frequency of the signal (0 <= frequency < 1/2)
realcons, the phase of the signal (0 <= phase < 2Pi)
realcons, the asymmetry of the signal (-Pi <= asymmetry < Pi)
container : Array, predefined Array for holding results
The GenerateTriangle(n, magnitude, frequency, phase, asymmetry ) command generates n samples for a triangular signal. The result is returned in an Array with datatype float.
The value of the magnitude argument must be positive.
The value of the frequency argument must be non-negative and strictly less than 12.
The phase argument must be non-negative and strictly less than 2⁢π.
The asymmetry argument must be greater than or equal to −π, and strictly less than π. When the value of asymmetry is equal to 0, the resulting triangle is symmetric.
If the container=C option is provided, then the results are put into C and C is returned. With this option, no additional memory is allocated to store the result. The container must be an Array of size n having datatype float.
The SignalProcessing[GenerateTriangle] command is thread-safe as of Maple 17.
For more information on thread safety, see index/threadsafe.
The SignalProcessing[GenerateTriangle] command was introduced in Maple 17.
For more information on Maple 17 changes, see Updates in Maple 17.
